| Battery | Maintenance free China brand 6V 220AH*24pcs. |
| Motor | AC72V 9KW |
| Controller | Curtis controller, AC type, USA brand |
| Charger | 72Vcharger 2pcs |
| Suspension: | Leaf Spring With Hydraulic Shock Absorbers |
| Braking system | Four wheels hydraulic braking system and independent parking brake , with brake pump |
| Steering | Rack and pinion steering with electric power steering |
| DC/DC Converter | 72V/12DC-30A |
| Passenger capacity | 23 |
| Range (loaded) (km) | 120km |
| Max. speed (km/h) | 20-40KM/H |
| Minimum turning radius (m) | 8.5 |
| Max. climbing ability (loaded) | 10% |
| Overall dimensions(mm) | 5900*1800*1960 |
| Max. loading weight(kgs) | 1840 |
| Gross weight(kgs) | 2000 |
| Chassis | Steel |
| Wheel base(mm) | 3420 |
| Ground clearance(mm) | 130 |
| Tires: | 195/70R15C |
| Body | Plastic+ABS |
| Windshield | One-piece see-through windshield laminated glass, with wiper |
| Dashboard | Fiberglass, battery capacity indicator, turning and speed indicator |
| Lights | Headlights, turning lights, reversing lights brake lights |
| Mirror | Side Mirror pair(left&right) |
