| Specification | 4C | 6C | 8C | 12C | |
| Rated capacity(including driver) | 4 | 6 | 8 | 12 | |
| Exterior dimensions | 3330*1640*1990mm | 4130*1570*1950mm | 4860*1570*1950mm | 5130*1640*1970mm | |
| Curb mass | 744kg | 845kg | 963kg | 1063kg | |
| Max.total mass | 1064kg | 1325kg | 1603kg | 2023kg | |
| Max.speed | 30km/h | 30km/h | 30km/h | 30km/h | |
| Driving Mileage | 80-100km standard lead acid battery, maintenance free type | 80-100km standard lead acid battery, maintenance free type | 80-100km standard lead acid battery, maintenance free type | 80-100km standard lead acid battery, maintenance free type | |
| Front tread | 1185mm | 1210 mm | 1165mm | 1265mm | |
| Rear tread | 1215mm | 1150 mm | 1165mm | 1270mm | |
| Grade capability | 20% | 20% | 15% | 0.15 | |
| Energy consumption(kwh) | >15 | >15 | >15 | >15 | |
| Suspension(front/rear) | Torison bar spring/independent suspension/stell plate spring | Torison bar spring/independent suspension/stell plate spring | Torison bar spring/independent suspension/stell plate spring | Torison bar spring/independent suspension/stell plate spring | |
| Brake type | Former dish brake/hub after brake | Former dish brake/hub after brake | Former dish brake/hub after brake | Former dish brake/hub after brake | |
| Frame | Aluminum | Aluminum | Aluminum | Aluminum | |
| Transmission case type | CVT | CVT | CVT | CVT | |
| Tire type | 175/70R14 | 175/70R14 | 175/70R14 | 175/70R14 | |
| Min.Ground clearance | 150mm | 150mm | 150mm | 150mm | |
| Drive system | |||||
| Motor | Motor type | AC motor | AC motor | AC motor | AC motor |
| Power | 5KW | 5KW | 5KW | 5KW | |
| Voltage | 48V | 48V | 48V | 72V | |
| Torque (N.m) | 13.65n.m | 13.65n.m | 13.65n.m | 13.65n.m | |
| Battery | Type | maintenance-free lead-acid cell | maintenance-free lead-acid cell | maintenance-free lead-acid cell | maintenance-free lead-acid cell |
| Voltage(V) | 8V *6pcs | 6V*8pcs | 6V*8pcs | 8V*9PCS | |
| Capacity (AH) | 150 | 180 | 180 | 150 | |
| Controller | High voltage rated voltage | 48V | 48V | 48V | 72V |
| Peak current virtual value | 400A | 400A | 400A | 400A | |
