| Battery | Customized Free Maintenace Battery,12Vx5pcs, 150AH |
| Motor | Customized 5KW AC motor |
| Controller | Japanese Imported Toyota AC Controller 60V350A |
| Charger | onboard charger 60V/20A |
| Transaxle | 12.49:1 viarable speed transaxle |
| Passenger capacity | 4 |
| Range (loaded) | 120km |
| Max. speed | 45km/h |
| Minimum turning radius | 4.8m |
| Max. climbing ability (loaded) | 20% |
| Brake distance | 4m |
| Overall dimensions:LWH (mm) | 2750*1280*1610mm |
| Min. ground clearance (mm) | 120mm |
| Gross Weight (with batery) | 685kg |
| Frame | Welded high yield strength tubular steel |
| Body | PP Plastic |
| Windshield&Skylight | Laminated glass &Full View Skylight |
| Seat cushion | plastic foam + artificial leather |
| Floor | Anti Slippery Rubber Floor |
| Dashboard | Key switch、combination switch,DVD&MP3 player、wipper,etc |
| Mirror inside/outside | with |
| Lighting system | Front light、turning light,reversing light、braking light、 buzzer、Emergency Light、AC |
| Reversing alarm | with |
| Speed meter | with |
| seat belt | 2 point ,4 pieces |
| Rear cargo box | with |
| air-conditioner | 60V/800W |
| Steering system | Dual automotive-style strut and self-adjust rack-and pinion steering |
| Brake system | Four Wheel Hydraulic Disc Brake+Handbrake |
| Accelerator | Electric accelerator |
| Suspension system | Helical spring with hydraulic shock absorber |
| Tyre+Rim | 12 inch tire（diameter 505mm）with steel rim |
