| Chassis | steel chassis, good for loading |
| Transaxle | Italy technoogy axle, aluminum gearbox house |
| Controller | USA Curtis controller |
| Battery | Chaowee 8V 150AH GEL battery |
| Motor | Japan brand DC KDS 4kw |
| Tyre | USA Carlisle 18*8.5-8 6 layers |
| Roof | PP plastic |
| Body | high quality injection plastic |
| Windshield | One piece windshield, plastic material |
| Charger | high smart charger, on board |
| battery Indicator | USA Curtis |
| Light system | front LED lights + rear LED lights |
| Mirror system | middle mirror + rear mirror |
| Horn | horn |
| Cargo box | Alluminum material, not steel, no rust, 1900*1150mm |
| steering system | dual self compensated rack and pinion |
| Brake | rear wheel drum brake |
| suspension | double A arm wisbone independent suspension |
| floor | plastic hard floor |
| windshield | car glass with wiper |
| Passenger capacity | 2 |
| Max. loading weight | 600kgs |
| Climbing capacity (Full load) | 20% |
| Ground clearance | 114mm |
| Max speed | 20km/h |
| F / R track | 860/970mm |
| Endurance | 70-80km |
| Cart dimensions | 3600*1200*1800mm |
| Weight(with batteries) | 590kgs |
| Max. brake movement | 2.4m |
| Min turning radius | 3.6m |
| Charging time | 8 hours |
| Wheelbase | 1670mm |
