| Battery | 6pcs 8V 180AH maintenance free battery | |
| Motor | DC48V4KW motor Japan Nidec Corporation made | |
| Controller | Curtis Controller, USA brand, | |
| Charger | on board charger 48V18A, | |
| Accelerator | Adjustable Inductive Accelerator Continuously Variable Speed System | |
| Suspension | Double A arm, independent suspension | |
| Steering | Self Compensating" Rack & Pinion" Steering | |
| Brakes | Rear wheel Mechanical Drum Brake & Regeneration Brake | |
| Passenger capacity | 2 | |
| Load range | 60-70 km | |
| Max. speed | 18-24 km/h | |
| Minimum turning radius | 4.2 | |
| Max. climbing ability | 20% | |
| Overall dimensions | 3400*1200*1900mm | |
| Max. loading weight | 640kgs | |
| Gross weight | 700kgs | |
| Chassis | Steel | |
| Front wheel Tread | 930mm | |
| Rear wheel Tread | 980mm | |
| Qty per contaienr | 3pcs/40HQ 1 pc /20GP | |
| Windshield | Foldable glass | |
| Dashboard | In black plastic finish , forward/reverse switch, battery capacity indicator, ignition key | |
| Beverage holders | 4 cups drink holders | |
| Lights system | Front lights, tail lights, turning lights, brake lights, horn | |
| Wheels | Steel 18*8.50-8,4Ply with rim decoration cover | |
| Body | engineering PP | |
